SECTION II
TM 9-2320-272-24P-1
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM SMR
PART
NO CODE
NSN
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
UOC:DAC, DAD, V16, V17, ZAC, ZAD
23
PFFZZ 5340010899128
19207 11611648-1
.BRACKET, BOGIE................................................
1
UOC:DAC, DAD, V16, V17, ZAC, ZAD
24
PAFZZ 5305009162345
80204 B1821BH075F200N .SCREW, CAP, HEXAGON H .................................
16
UOC:DAC, DAD, V16, V17, ZAC, ZAD
25
PAFZZ 5310002416664
96906 MS51943-44
.NUT, SELF-LOCKING, HE ....................................
12
UOC:DAC, DAD, V16, V17, ZAC, ZAD
26
PAFZZ 5310009353569
96906 MS51943-46
.NUT, SELF-LOCKING, HE ....................................
16
UOC:DAC, DAD, V16, V17, ZAC, ZAD
27
PAFZZ 5305007195239
96906 MS90727-116
.SCREW, CAP, HEXAGON H..................................
16
UOC:DAC, DAD, V16, V17, ZAC, ZAD
28
PAFZZ 5340012919212
19207 12301265
.LOOP, STRAP ....................................................
10
UOC:DAC, DAD, V16, V17, ZAC, ZAD
29
PAFZZ 5310001808544
19207 10872159
.WASHER, FLAT ...................................................
20
UOC:DAC, DAD, V16, V17, ZAC, ZAD
30
PAFZZ 5310008775795
96906 MS21044-N8
.NUT, SELF-LOCKING, HE .....................................
2
UOC:DAC, DAD, V16, V17, ZAC, ZAD
31
PAFZZ 5305007262550
80204 B1821BH063F175N .SCREW, CAP, HEXAGON H..................................
12
UOC:DAC, DAD, V16, V17, ZAC, ZAD
32
XBHZZ
19207 12255988
.CROSSMSEBER..................................................
1
UOC:DAC, DAD, V16, V17, ZAC, ZAD
33
PFFZZ 5320011453186
24617 425923
.RIVET, SOLID ......................................................
9
UOC:DAC, DAD, V16, V17, ZAC, ZAD
34
PBHZZ 2510010889157
19207 12256028
.FRAME SECTION, STRUC ...................................
2
UOC:DAC, DAD, V16, V17, ZAC, ZAD
35
PBHZZ 2510010889156
19207 12256036
.FRAME SECTION, STRUC ...................................
1
UOC:DAC, DAD, V16, V17, ZAC, ZAD
36
PFHZZ 2510010885914
19207 12256033
.FRAME SECTION, STRUC SEE FIG. 325...............
1
FOR A2s .............................................................
UOC:DAC, DAD, V16, V17
37
PAFZZ 5305007250154
96906 MS90727-112
.SCREW, CAP, HEXAGON H .................................
4
UOC:DAC, V16, V17
38
PAFZZ 5310008095998
96906 MS27183-18
.WASHER, FLAT ..................................................
4
UOC:DAC, V16, V17
39
PBFZZ 5340011704940
19207 12302672
.BRACKET, MOUNTING.........................................
1
UOC:DAC, V16, V17
40
PAFZZ 5310004883888
96906 MS51943-40
.NUT, SELF-LOCKING, HE ....................................
4
UOC:DAC, V16, V17
41
PAFZZ 5305007195221
80204 B1821BH050F150N .SCREW, CAP, HEXAGON H .................................
4
UOC:DAC, DAD, V16, V17, ZAC, ZAD
42
PAFZZ 5320011453184
24617 142392
.RIVET, SOLID ......................................................
14
UOC:DAC, DAD, V16, V17, ZAC, ZAD
43
PFHZZ 5342011647597
19207 12277352-1
.BRACKET, SPECIAL ............................................
1
UOC:DAC, DAD, V16, V17, ZAC, ZAD
44
PFHZZ 3040010889161
19207 8758403
.BRACK ET, EYE, NONROTA ..................................
2
UOC:DAC, DAD, V16, V17, ZAC, ZAD
45
PAOZZ 5305007250140
96906 MS90727-139
.SCREW, CAP, HEXAGON H..................................
14
UOC:DAC, DAD, V16, V17, ZAC, ZAD
46
XAHZZ
19207 12256340
.RAIL ASSY SEE FIG. 325 FOR A2s .......................
1
UOC:DAC, DAD, V16, V17, ZAC, ZAD
47
PFOZZ 2510007409337
19207 7409337
.SHACKLE, LEAF SPRING ....................................
4
UOC:DAC, DAD, V16, V17, ZAC, ZAD
48
PAOZZ 5310002416661
96906 MS51943-42
.NUT, SELF-LOCKING, HE ....................................
16
UOC:DAC, DAD, V16, V17, ZAC, ZAD
323-2
